TPSN M-12X1.75-N HEST
HSS straight flute machine taps - ISO metric coarse threads, according to DIN 13, for low Carbone Steel
Price: Log in For Price
| Thread Diameter Size (TDZ) | M12 | Coating | Steam tempered |
| Thread Pitch (TP) | 1.75 mm | Measurement Type | Metric |
| Overall Length (OAL) | 110 mm | Grade | HEST |
| Thread Cutting Part Length (THL) | 18 mm | Application | | Deep Hole with Short Thread | Taps for Deep Blind Hole | Taps for Short Blind Hole | |
| Connection Diameter Machine Side (DCONMS) | 9 mm | Body Material | HSS |
| Flute Count (NOF) | 3 | Drive Size (DRVS) | 7 mm |
| Cutting Edge Material | HSS | Thread Size | M12 × 1.75 |
| Standard | DIN 376 | Unit | M |
| Tool Type | Machine Blind Hole Taps |
Product Features
| Family Description | HSS straight flute machine taps - ISO metric coarse threads, according to DIN 13, for low Carbone Steel | COO | Hungary |
Shipping Info
Weight per item
0.0580
